LX2550/LX2650

Dimensions (mm)

L550/L650*W430*H89mm

Material

Heavy-SGCC 1.0mm Zinc-coated steel

Cooling

3 x 8025mm fans (Middle)

Front Panel Controller

1x Power, 1x Reset,
2x USB2.0

LED Indicators

1x Power Led,1x HDD Led,2x NIC Leds

Drive Bays

External: N/A
Internal:  6*3.5”/2*2.5“Bays

System Board

12”*9.6”(ATX), 9.6”*9.6”(m-ATX), 17*17cm(ITX)
LX2650--max 12"*13"

Expansion Slots

7x Half Height Slots

Power Supply

1UPSU 250W~500W;2U PSU 600W/ 850W.
ATX PSU 300W~500W.LX2650--CRPS more.

Color

Front- Coated in Black;
OEM Available.

Package Dimension

LX2550-645*520*175mm,
LX2650-745*520*175mm,

Net Weight

LX2550-,GW.10kgs
LX2650-GW.12kgs

Gross Weight

Mounting Kits

Option L Rack kits/
Rack Sliding Rails---SR122

custom services

support

Order Code

M/B

HDD Backplane

PSU

Rear Window

Slide Rail

CS15604A6

12"x10.5"

4-Bay 2.5"/3.5", 6GB SATA

Option 400W/500 1U single

1-Slot,HF

Option

CS15604M6

12"x10.5"

4-Bay 2.5"/3.5", 6GB mini SAS

Option 400W/500 1U single

1-Slot,HF

Option

CS15604G12

12"x10.5"

4-Bay 2.5"/3.5", 12GB mini SAS HD SGPIO

Option 400W/500 1U single

1-Slot,HF

Option

CS16504A6

12"x13"

4-Bay 2.5"/3.5", 6GB SATA

Option 500 1U single

1-Slot,HF

Option

CS16504M6

12"x13"

4-Bay 2.5"/3.5", 6GB mini SAS

Option 500 1U single

1-Slot,HF

Option

CS16504G12

12"x13"

4-Bay 2.5"/3.5", 12GB mini SAS HD SGPIO

Option 500 1U single

1-Slot,HF

Option

CT16510G12

12"x13"

10-Bay 2.5", 12GB mini SAS HD SGPIO

Option 500 1U single

1-Slot,HF

Option
