Form Factor |
Workstation,Tower&Rackmount Chassis |
M/B Form Factor |
Motherboard MAX 15.2"x13.2". Eg:Supermirco X10DRG-Q/X11DPG-QT/X12DPG-QT6/Tyan S7106 etc. |
Dimensions (Dx Wx H) |
650 x 437.5 x 176.5(mm) |
Material |
High quality Anti-finger 1.0 mm SGCC& Super ABS ROSHs |
Front Control |
1x Power On/Off, 1x System Reset, 2 x USB 3.0 |
Indicators |
1x Power Status, 2x LAN Activity, 1x HDD Status |
Hotswap Backplane |
1)6GB SATA Hot-swap Backplane (Default) 2)12GB Mini SAS HD SGPIO Hot-swap Backplane(option) 3)Nvme Hot-swap Backplane,support SATA/SAS/Nvme(option) |
Drive Bays |
External 3.5"/ 2.5":4(Hotswap,SATA/SAS/Nvme,Nvme optional) Slim DVD-ROM:1 |
Cooling Fans |
Default 3x 120mm(T=38mm), PWM (Middle), |
Expansion Slots |
11x Full Height |
PSU Form Factor |
Option CRPS 80Plus Platinum Redundant power supply. |
Color |
Coated Black (Others customized) |
Application |
Cloud Storage, Cloud Computer, Huge Storage,Datacenters, NVR, Security Monitor Industry etc. |
Net Weight |
21.15Kg |
Gross Weight |
23.50Kgs |
Unit Carton Size |
82*60*34CM |
Customized |
Available |
Option Item | Part Number | Description |
---|---|---|
Slide Rail | TR713 | Rack Sliding Rails |
Power Supply | CRPS-1300W | 80Plus Platinum CRPS Redundant PSU |
Power Supply | CRPS-1600W | 80Plus Platinum CRPS Redundant PSU |
Power Supply | CRPS-2000W | 80Plus Platinum CRPS Redundant PSU |
Power Supply | CRPS-2700W | 80Plus Platinum CRPS Redundant PSU |
Motherboard | ASUS/Supermirco | Becool 40x20mm PWM Dual-Balling 10,000RPM |
Optional BP | 4*Nvme/SATA/SAS | 12Gb Mini HD Nvme BP |
CPU Cooler | 4U/Workstation | LGA4189/1700/3647/SP3/SP5 |
