●High-density design for space saving L=480mm;
●Front access USB 2.0 port/3.0 port
Welcome to Shenzhen Innovision Technology Co.,Ltd
●High-density design for space saving L=480mm;
●Front access USB 2.0 port/3.0 port
|
Model |
G4808 |
|||
|
Chassis |
Form Factor |
4U Standard 19”Rack-mount |
||
|
Size（L*W*H） |
437.5(W)*480(D)*176.5(H)mm |
|||
|
Cooling Fans |
3*12038(Middle) PWM Dual Balling High Speed Fans |
|||
|
Material |
1.0mm Superior SGCC，Front-Coated in Black |
|||
|
Motherboard |
System chipset |
Support Max 12"*13" Board |
||
|
Memory |
Option |
|||
|
I/O interface |
USB Port |
2*USB2.0 (Option USB3.0）Front |
||
|
FP Controller |
LED/Switch |
Power LED*1，Reset*1，Power SW*1 |
||
|
Storage |
SATA/M2/Msata |
4*2.5”SSD Bays |
||
|
Expansion |
Chassis Slot |
8*PCI/PCIe Full Profile Expansion slot (Support 3~4 Dual Slot GPU Card） |
||
|
Powersupply |
Form Factor |
ATX Or 2U 1+1 CRPS QTY:2 Modules |
||
|
Item No |
1300W Platinum |
1600W Platinum |
2000W Titanium |
|
|
Application |
Widely in |
AI、Edge Computing、Deep-Learning Computer、Rendering，GPU High Speed Computing etc. |
||
| Option Item | Part Number | Description |
|---|---|---|
| Slide Rail | TR101 | 2Section Rack Sliding Rails |
| Power Supply | Flex 1U 250W | ENP-7025B, 1U Flex 250W, 80 Plus Bronze |
| Power Supply | Flex 1U 400W | ENP-7140B, 1U Flex 400W, 80 Plus Gold |
| Power Supply | 1U 300W/400W | ENH-1930/1940, 1U 300W/400W, 80 Plus |
| Power Supply | 1U 500W | Delta 1U 500W, 80 Plus Gold |
| Power Supply | 1U Redundant | CRPS 1+1 1U 450W |
| Fan | 402HBVH-M1U | Becool 40x20mm PWM Dual-Balling 10,000RPM |
| Fan | AVC | AVC 40x20mm PWM Dual-Balling 7,000RPM |
| Fan | Default | JHX 40x20mm 3Pin 5,000RPM |
| Riser Card | 08548G | R1U PCIe x16 riser Card |
| Back I/O Shield Plate | Custom | Rear I/O shield-According M/B |
 |
